Rim Type Panic Exit Device-Fire Rated

Rim Type Panic Exit Device-Fire Rated :
  • Address: XXXX

  • Business Type: Manufacturer



Product Specification

Rim Type Panic Exit Device-Fire Rated

Model: 1021F Product Specifications: Well Laud is a manufacturer of exit device rim type that are manufactured under strict standards. We have been developing through years of experience and accumulated know-how from the global market. 1. Conforms to UL Listed (Fire Rated Model 3 Hours) 2. Conforms to Ansi STD A156. 3 Grade 1 3. Fire Rated 4. Use on: -Door width from 30"~48" -Door height 84"~96" -Door thickness: Standard: 1-3/4". 1-3/8" to 2" thick doors are available 5. Stile: Minimum 4-1/2" 6. Non- Handed 7. Latch Bolt: 3/4" throw stainless steel 8. Dead Latch Bolt: 5/8" stainless steel 9. Strike: 5/8" stop plus shim for 1/2" stop 10. Dogging feature: Allen-Key 11. Material: Steel or Stainless steel -Cover: Zinc or Stainless steel 12Finish: -Painted: Aluminum, Bronze, Duronodic -Solid stainless steel: Highly polished or Stain Note Country of Origin: Taiwan Sales Methods: Export, Manufacture Delivery Time: 45 days after receiving the deposit

Year of Establishment

1986

Legal Status of Firm

Nature of Business

Manufacturer

GST

WI Member Since

1986
